| 规格 | 螺纹 | D±0.05 | F±0.1 | G 螺纹内径 |
C ±0.1 |
L ±0.1 |
B（仅盲孔） +0.5 |
| GB809 M2*4*3 | M2 | 4 | 3 | 1.6+0.08 | 0.1 | 3 | / |
| GB809 M2*4*4 | 1 | 4 | / | ||||
| GB809 M2*4*5 | 1.5 | 5 | 2.5 | ||||
| GB809 M2*4*6 | 2 | 6 | 3 | ||||
| GB809 M2*4*8 | 2.5 | 8 | 4 | ||||
| GB809 M2*4*10 | 3 | 10 | 6 | ||||
| GB809 M2.5*4.5*3 | M2.5 | 4.5 | 3.8 | 2.05+0.1 | 0.6 | 3 | / |
| GB809 M2.5*4.5*4 | 1 | 4 | / | ||||
| GB809 M2.5*4.5*5 | 1.5 | 5 | 2.5 | ||||
| GB809 M2.5*4.5*6 | 2 | 6 | 3 | ||||
| GB809 M2.5*4.5*8 | 2.5 | 8 | 4 | ||||
| GB809 M2.5*4.5*10 | 3 | 10 | 6 | ||||
| GB809 M2.5*4.5*12 | 3 | 12 | 8 | ||||
| GB809 M3*5*4 | M3 | 5 | 4 | 2.5+0.1 | 1 | 4 | / |
| GB809 M3*5*5 | 1.5 | 5 | / | ||||
| GB809 M3*5*6 | 2 | 6 | 3 | ||||
| GB809 M3*5*8 | 2.5 | 8 | 4 | ||||
| GB809 M3*5*10 | 3 | 10 | 6 | ||||
| GB809 M3*5*12 | 3 | 12 | 8 | ||||
| GB809 M3*5*15 | 4 | 15 | 10 | ||||
| GB809 M3*5*20 | 2.5+0.12 | 5 | 20 | 12 | |||
| GB809 M4*6*4 | M4 | 6 | 5 | 3.3+0.1 | 1 | 4 | / |
| GB809 M4*6*5 | 1.5 | 5 | / | ||||
| GB809 M4*6*6 | 2 | 6 | 3 | ||||
| GB809 M4*6*8 | 2.5 | 8 | 4 | ||||
| GB809 M4*6*10 | 3 | 10 | 6 | ||||
| GB809 M4*6*12 | 3 | 12 | 8 | ||||
| GB809 M4*6*15 | 4 | 15 | 10 | ||||
| GB809 M4*6*20 | 3.3+0.12 | 5 | 20 | 12 | |||
| GB809 M5*8*5 | M5 | 8 | 7 | 4.1+0.1 | 1.5 | 5 | / |
| GB809 M5*8*6 | 2 | 6 | / | ||||
| GB809 M5*8*8 | 2.5 | 8 | 4 | ||||
| GB809 M5*8*10 | 3 | 10 | 6 | ||||
| GB809 M5*8*12 | 3 | 12 | 8 | ||||
| GB809 M5*8*15 | 4 | 15 | 10 | ||||
| GB809 M5*8*20 | 4.2+0.12 | 5 | 20 | 12 | |||
| GB809 M6*10*5 | M6 | 10 | 8.5 | 5.0+0.1 | 1.5 | 5 | / |
| GB809 M6*10*6 | 2 | 6 | / | ||||
| GB809 M6*10*8 | 2.5 | 8 | 4 | ||||
| GB809 M6*10*10 | 3 | 10 | 6 | ||||
| GB809 M6*10*12 | 3 | 12 | 8 | ||||
| GB809 M6*10*15 | 4 | 15 | 10 | ||||
| GB809 M6*10*20 | 5 | 20 | 12 | ||||
| GB809 M8*12*6 | M8 | 12 | 10 | 6.8+0.1 | 2 | 6 | / |
| GB809 M8*12*8 | 2.5 | 8 | / | ||||
| GB809 M8*12*10 | 3 | 10 | / | ||||
| GB809 M8*12*12 | 3 | 12 | 8 | ||||
| GB809 M8*12*15 | 4 | 15 | 10 | ||||
| GB809 M8*12*20 | 6.8+0.12 | 5 | 20 | 12 | |||
| GB809 M8*12*25 | 6 | 25 | 15 |
